Description
FEATURES
- Operate with ease and efficiency using the optional field-installed mechanical self-leveling (MSL) loader
- Quik-Park™ loader mounting system
- Quik-Change attachment carrier
- End-of-pin lubrication on cylinder and pivot pins allows easy access for servicing grease points
TECHNICAL SPECIFICATION
Maximum lift height (A): 2160 mm / 85 in.
Lift capacity at full height: Measured at pivot (U): 509 kg / 1120 lb. Measured at 500 mm ahead of pivot (V): 365 kg / 803 lb.
Boom breakout force: Measured at pivot (Y): 886 kg / 1949 lb. Measured at 500 mm ahead of pivot (Z): 618 kg / 1360 lb.
Bucket rollback force capacity: At ground-level line (ZZ): 972 kg / 2138 lb
Clearance at full height – bucket dumped (C): 1667 mm / 66 in.
Dump angle, degrees (E): 36 degree (angle)
Rollback angle, degrees (G): 34 degree (angle)
